“We wanted to make the Raven disc screen versatile, cost-effective, and user-friendly. A key feature of our disc screen is its modular screening table, which allows for quick adjustments to the desired particle size in just 15 minutes.” says Eetu Tuovinen, Product Manager, Recycling.
High-volume throughput – guaranteed.
The TANA Raven X550T disc screen, by default, separates material into two fractions – oversize and undersize – but can be equipped with an optional three-fraction screening package for finer separation. This versatility is enabled by Tana’s patented modular screening table, which consists of four interchangeable modules, allowing quick adjustments to achieve different particle sizes.
For instance, the first quarter of the table can separate fines under 20 mm, while the rest screens medium fractions between 20–100 mm, with larger materials classified as oversized. The modular design also allows future modifications, and the development of new particle size options based on customer needs.
Built on years of engineering advancements for high-throughput performance, it efficiently processes large volumes solid waste—ensuring seamless, uninterrupted operations.
Straightforward structure without complex components
The discs are efficiently and precisely manufactured by injection molding, this offers a simple, quiet, durable, and cost-efficient design. The smart anti-wrapping design also eliminates the need for separate anti-wrapping systems, making spares and wears simpler and more affordable for our customers. Additionally, the discs weigh up to 75% less than steel discs, enhancing efficiency. The unique design of the screen discs is also patent protected.
“The smart TANA Control System (TCS) detects jams and can reverse the machine when needed. The system also allows users to store different programs for processing various materials,” Tuovinen explains.
TANA Raven can be used as a stand-alone machine in the waste process. However, it truly excels when paired with other TANA solutions. TANA shredders and the disc screen form an ideal mobile processing duo, operating at the same speed and handling the same waste types seamlessly.
Like its namesake in the animal kingdom, the TANA Raven is highly adaptable and intelligent. Its disc screen component enhances this flexibility, efficiently handling various waste types with high capacity, particularly MSW, C&D, and waste wood. Designed for ease of operation, the disc screen features a large hopper, allowing smooth and continuous feeding with a wheeled loader.
One of the stand-out features of the TANA Raven’s disc screen is its adjustable tilt function. This capability not only enhances material flow but also allows operators to fine-tune the screening process to meet specific requirements. As a result, the system adapts effortlessly to different waste fractions while maintaining consistent and reliable performance.
Key Benefits:
- Patented design for durability and efficiency
- The most versatile screening solution
- Screens almost everything with minimal clogging
TanaConnect® at your service
TanaConnect® is a fleet management system that collects, analyzes, and presents machine data to streamline operations, boost team motivation, and enhance productivity.
A live machine overview provides detailed insights into its condition and performance. Information from the TanaConnect® portal can also be integrated with other systems, such as maintenance management, production management, or ERP systems via the TanaConnect® API. The digital portal enables real-time fleet management, keeping users consistently up to date with the following key information:
- Machine health information
- Production reports
- Machine alarms
- Machine events
- Machine service information
- TANA documents
Screening solution for you to take the lead
Its advanced design, patented modular system, and smart technology put you ahead of the competition in efficiency, adaptability, and cost-effectiveness. With user-friendly operation and minimal downtime, it ensures maximum productivity in demanding waste processing environments.
